SAMI-AEC Masseh

Seamless Integration, Unmatched Security

At SAMI-AEC, we understand that security needs differ across sectors. That's why our UVSS system isn't
one-size-fits-all. It's versatile, customizable, and seamlessly integrates to enhance security in various
environments. Perfect for government, military, corporate, and transportation facilities, our system ensures
thorough undercarriage inspection wherever needed. Trust SAMI-AEC to provide tailored solutions that meet
your security needs with precision and reliability.

Adaptable & Dynamic Vehicle
Security Screening

SAMI-AEC

Superior threat detection with
high-resolution cameras and
AI-powered video analytics

SAMI-AEC

Easy installation and
maintenance with a compact
and durable platform

SAMI-AEC

Efficient operation with
automated license plate
recognition and anomaly
detection

Shielding KSA’s Infrastructure with
Revolutionary Under Carriage Inspection

Intuitive Checkpoint Interface
for Optimized Security

Undercarriage images saved
with recognized license
plates, and optionally, driver
and passenger faces,
for future analysis

Simultaneous
comparison of images,
allowing operators to
identify and mark
suspicious areas, and
make access decisions
within a single interface

Ability to use undercarriage
scans as reference images
for comparison and Foreign
Object Detection (FOD) upon
the vehicle's return

Customizable user
interface for seamless
workflow in vehicle
passage checks

Core Modules of Integrated
Control System

Under Vehicle
Scanning Platform

Under Vehicle Scanning Solution Specifications

Scanning camera: 2MP Area scan machine vision camera

Pixel density: 18 pixels/cm

Max vehicle speed: Up to 15-22 mph (25-35 km/h)

Minimum vehicle ground clearance: 3.9 inches (100 mm)

Maximum vehicle ground clearance: No less than 20-40 inches (500-1000 mm)

Lighting system: 12 white-light LEDs (strobe mode, synchronized with active camera shutter)

Load capacity: Up to 30 tons per axle (up to 3 tons dome protection area)

Operating temp: -40°F … up to +158°F (-40°С … up to +70°С)

Power: 48 VDC Passive POE / (45 W – average; 95 W – peak)

Dimensions (LxWxD): 38.2 in x 12.2 in x 7.7 in (970 mm x 310 mm x 195 mm)

Weight: Up to 55.1 lbs. (25 kg)

IP68

LPR/ANPR Camera

Under Vehicle Scanning Solution Specifications

Resolution: 4MP (2560x1440)

Sensor Type: CMOS, 1/1.8”, Color

Lens: Varifocal, 8mm to 32mm

Zoom / Focus: Adjustable, Motorized

Illumination: White Light / IR

Illumination Distance: 65.62ft (20m)

Max Power Consumption: 21W

Input Voltage: 12 VDC (-10%, +25%), 24VAC ±25%, or PoE+ (IEEE802.3)

Operating Temp: -22°F to +140°F (-30°C to +60°C)

Weight: 3.60 lbs (1.65 kg)

Dimensions (LxWxH): 12.10” x 4.10” x 3.87” (306.60mm x 104.10mm x 98.4mm)

FCC / CE

IP67 / IK10

Driver Camera

Under Vehicle Scanning Solution Specifications

Lens focal length: 16/25/50 mm depending on installation point, fixed

Illumination: 15° full angle IR lighting unit modules

Supported vehicle speeds: 90 km/h (55 mph)

Operating Temp: -40°С … +60°С

Power Consumption: 48 VDC

Dimensions (LxWxH): 16.14x7.09x6.69 inches (410x180x170 mm)

Weight: 11.46 lb. (5.2 kg)

IP67 / IK10

Server running the AI software

SAMI-AEC Masseh UVSS Platform

Technical Specifications

SAMI-AEC Masseh UVSS Platform Specifications

Scanning camera

2MP Area scan machine
vision camera

Pixel density

9 pixel/cm (with ground clearance
of 5.9 inches/150mm)

Maximum vehicle speed

22 mph (35 km/h)

Minimum vehicle clearance

4.7 inches (120mm)

Maximum vehicle width

Up to 8.5 ft/2.6 m (if ground
clearance is 5.9 inches/150mm)

Maximum vehicle length

Up to 72.18 ft (22 m)

Minimum pause
between scans

3 seconds

LPR/ANPR coverage

More than 100 countries
supported worldwide

Lighting system

8 white light LEDs (strobe mode,
synchronized with active camera shutter)

Image processing time

Up to 3 seconds (for passenger
vehicle)

Load Capacity

Up to 40 tons

Protection Rating

IP68, IK10

Operating Temperatures

-40°F to +140°F
(-40°С to +60°С)

Power

24 V DC / (50 W – average;
100 W – peak)

UVSS platform weight

Up to 55.1 lbs. (25 kg)

Electromagnetic
immunity and emissions
certification

FCC Part 15, Subpart B / EN
55032:2015 / EN 55024:2010 /
IEC 61000-6-3:2007+A1:2010 /
IEC 61000-6-2:2005

Dimensions (LxWxD)

38.2 in x 12.2 in x 7.7 in
(970 mm x 310 mm x 195 mm)

Dimensions of camera
protection body

D = 3.5 in, H = 5.4 in
(D = 90 mm, H = 137 mm)

Mounting configuration

Semi-hidden installation (road drilling
only for camera protective body)

Warranty period

1 year

Order Information

ISS-UVSS-H

SecurOS® UVSS Scanning Platform. Includes Power supply - 24 VDC output (120 W).
** Cannot be purchased separately without SecurOS® UVSS Module Software (ISS-UVSS-S)

ISS-UVSS-S

SecurOS® UVSS Module Software license (1 license required for each UVSS Scanning Platform).
** Cannot be purchased separately without SecurOS® UVSS Scanning Platform (ISS-UVSS-H)

ISS-UVSS-HS

SecurOS® UVSS Scanning Platform PLUS SecurOS® UVSS Module Software BUNDLE.
Includes Power supply - 24 VDC output (120 W)

ISS-UVSS-CON-R

SecurOS® UVSS Controller (Server).
Includes 5 Year Next Business Day KYHD Warranty
